The Jiexun four-way shuttle car is a kind of intelligent handling robot working on the track, which can realize the tasks of goods warehousing, inventory and placement under the control of the system, and can communicate with the upper computer and WMS system or control through the handheld terminal, and realize the functions of automatic identification and automatic access in combination with electronic labels, bar codes and other technologies.
It is the main mechanism for storing and storing goods, with automatic retraction function. It is directly assembled on the shuttle car, which is convenient to pass through the lane between the shelves and complete the work of automatic access or transfer of goods.
Variable cargo fork
It can automatically change the fork distance according to the size of the goods, and access them.
Double deep fork
It is the same as the single depth level, but the pickup distance is farther, and can be extended to two bins. It is directly mounted on the four-way shuttle.
Why Choose Shuttle Cars?
Multi-layer shuttle robot is the fastest paced product in the storage industry in today's society. The efficiency of multi-lane entry and exit can reach 2000+boxes/h. It is the preferred product for large box-type high-level stereoscopic warehouse. In the same site, the speed can reach 1.2 times/1.5 times of the stacker and 1.5 times/3 times of the AGV bin robot, which is the fastest return on investment at present.
Manpower
Driving speed: 0.8m/s
Multiple roadway
Maximum beat of 50m roadway: 45 cases/hour
Investment return period: labor hours * 3650 hours/year
Mainly suitable for scenarios: small warehouses, start-ups.
At present, Jiexun is the only company in the world that focuses on the R&D, production and manufacturing of the bin shuttle robot and specializes in special price. It is committed to providing customers with a complete set of intelligent storage product solutions, including the bin shuttle, elevator, shelf, sorting line, software, etc., and implements delivery in 7 days and online in 30 days.
We have a very high degree of automated production equipment, which is more efficient and can effectively reduce manufacturing costs. And we always believe that only by providing customers with competitive products and prices can we make customers more competitive and ultimately grow with customers. After all: cooperation is win-win!
Jiexun sorting and conveying system is composed of lifting and transferring, roller conveying line, and goods sorter. The lifting and transferring is used to change the conveying direction of goods and send goods into or out of the main conveying line from the turnoff.The roller conveyor line is the main transport carrier in the conveying system. It can be combined with the jacking and load transfer device and shape detection device to form a complete system. According to customer requirements, there may be sorting processes in the outbound process, which are sorted manually at the sorting machine.
Precision track system of four-way shuttle car
The standard four-way car system is composed of the rack body, shuttle car elevator, maintenance platform and conveying system. The main part of the rack contains the shuttle precision guide rail with the accuracy of ± 1mm. Each cargo space also has a limit design to prevent the displacement of the goods. The elevator is divided into layer change elevator and cargo elevator. A maintenance platform is designed every three meters for the maintenance of technicians in the rack, and the final conveying system is mainly composed of roller conveying line.
Precision track system of two-way shuttle
The system layout of the standard two-way car is roughly the same as that of the four-way car, with two main differences: 1. There is no reversing for the two-way car, so each lane can be considered as a separate system. 2. The hoist of the two-way car is a new two-in-one hoist, which takes into account the role of the floor change and cargo hoist.
Sort conveyor system
Jiexun sorting and conveying system is composed of lifting and transferring, roller conveying line, and goods sorter. The lifting and transferring is used to change the conveying direction of goods and send goods into or out of the main conveying line from the turnoff.The roller conveyor line is the main transport carrier in the conveying system. It can be combined with the jacking and load transfer device and shape detection device to form a complete system. According to customer requirements, there may be sorting processes in the outbound process, which are sorted manually at the sorting machine.
Precision track system of four-way shuttle car
The standard four-way car system is composed of the rack body, shuttle car elevator, maintenance platform and conveying system. The main part of the rack contains the shuttle precision guide rail with the accuracy of ± 1mm. Each cargo space also has a limit design to prevent the displacement of the goods. The elevator is divided into layer change elevator and cargo elevator. A maintenance platform is designed every three meters for the maintenance of technicians in the rack, and the final conveying system is mainly composed of roller conveying line.
Jiexun short video platform
Several anchors will explain the relevant knowledge of the four-way shuttle to you.
Jiexun is a national high-tech enterprise and software enterprise, focusing on the research and development and manufacturing of light high-speed storage robots. The single lane of the Jiexun multi-shuttle system is up to 2000 boxes/hour. At present, it is the fastest solution in the world. It is committed to providing users with "high-quality, cost-effective, and highly reliable" products and services.
